CF1390
Chengfeng
CO2 Laser Engraving Cutting Machine 1390
DSP control, LCD display, cutting file and route is showing on the display. Laser output power and working speed can be set on this panel (and in machine software as well).
Emergency stop button.
Ampere meter for better observation of laser tube and laser power supply working condition.
Water cooling system
water pump / water chillers
S&A brand water chillers, best in china, it is used to cool the laser tube. Different chiller models are available for different wattage laser tubes: CW-3000, 5000, 5200, etc.
Laser power supply
supplying stable power for laser tube.
anodized aluminum blade table is suitable for hard sheet materials, such as acrylic, wood, MDF, etc.
Honeycomb worktable is for soft materials such as cloth, fabric, leather, etc.
RDC6442S DSP offline controller, designs/files can be transferred by the controller cable (blue cable) or by USB flash as well.
All wires are labeled with numbers, convenient for checking and maintenance.
Air pump
(1) Pushes fumes away from the optical lens to protects the it from contaminants which could damage the lens.
(2) Blows air to the material, removes heat and cools the material, protect your material or product from burning or heat, to get better engraving cutting effect.
Exhaust fan / extractor
Removes smoke and dust caused during engraving and cutting. The pipe is 6-meter long.
Technical parameter
Machine model | CF1390 laser engraving cutting machine |
Laser type | Sealed CO2 laser tube, wavelenght:10.64μm |
Laser power | 60W/80W/100W/150w/180w |
Cooling mode | Circulating water cooling |
Laser power control | 0-100% software control |
Control system | Ruida DSP offline control system |
Max. engraving speed | 60000mm/min |
Max cutting speed | 50000mm/min |
Repetition accuracy | ≤±0.01mm |
Min. Letter | Chinese:1.5mm, English:1mm |
Table size | 1300*900mm |
Working voltage | 110V/220V.50-60HZ |
Working conditions | temperature:0-45℃,humidity:5%-95% |
Control software language | English/Chinese |
File formats | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*.las,*.doc |
Tool box
Machine power cable, controller cable, spanners, lens cleanning paper, laser software, ruler, keys, glasses, bolts, spare limit switches, etc.
1. Motorized up-down table.
With this function, the machine table can be lifted in Z direction (up-and-down) to get more working space. It is necessary if you use rotary or engrave/cut items thicker/higher than 50mm.
2. Rotary (2 types)
It is used to hold and rotate cylindrical items during engraving and cutting, such as wine bottles, glasses, mugs, pipes, etc.
3. Red dot
Laser is invisible. Red dot shows the laser position on material, for better locating.
4. Auto focusing
Auto focusing has to work together with motorized up-down table. The machine adjusts the focal length automatically before engraving and cutting, which replaces manual focusing, improving working efficiency
CO2 Laser Engraving Cutting Machine 1390
DSP control, LCD display, cutting file and route is showing on the display. Laser output power and working speed can be set on this panel (and in machine software as well).
Emergency stop button.
Ampere meter for better observation of laser tube and laser power supply working condition.
Water cooling system
water pump / water chillers
S&A brand water chillers, best in china, it is used to cool the laser tube. Different chiller models are available for different wattage laser tubes: CW-3000, 5000, 5200, etc.
Laser power supply
supplying stable power for laser tube.
anodized aluminum blade table is suitable for hard sheet materials, such as acrylic, wood, MDF, etc.
Honeycomb worktable is for soft materials such as cloth, fabric, leather, etc.
RDC6442S DSP offline controller, designs/files can be transferred by the controller cable (blue cable) or by USB flash as well.
All wires are labeled with numbers, convenient for checking and maintenance.
Air pump
(1) Pushes fumes away from the optical lens to protects the it from contaminants which could damage the lens.
(2) Blows air to the material, removes heat and cools the material, protect your material or product from burning or heat, to get better engraving cutting effect.
Exhaust fan / extractor
Removes smoke and dust caused during engraving and cutting. The pipe is 6-meter long.
Technical parameter
Machine model | CF1390 laser engraving cutting machine |
Laser type | Sealed CO2 laser tube, wavelenght:10.64μm |
Laser power | 60W/80W/100W/150w/180w |
Cooling mode | Circulating water cooling |
Laser power control | 0-100% software control |
Control system | Ruida DSP offline control system |
Max. engraving speed | 60000mm/min |
Max cutting speed | 50000mm/min |
Repetition accuracy | ≤±0.01mm |
Min. Letter | Chinese:1.5mm, English:1mm |
Table size | 1300*900mm |
Working voltage | 110V/220V.50-60HZ |
Working conditions | temperature:0-45℃,humidity:5%-95% |
Control software language | English/Chinese |
File formats | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*.las,*.doc |
Tool box
Machine power cable, controller cable, spanners, lens cleanning paper, laser software, ruler, keys, glasses, bolts, spare limit switches, etc.
1. Motorized up-down table.
With this function, the machine table can be lifted in Z direction (up-and-down) to get more working space. It is necessary if you use rotary or engrave/cut items thicker/higher than 50mm.
2. Rotary (2 types)
It is used to hold and rotate cylindrical items during engraving and cutting, such as wine bottles, glasses, mugs, pipes, etc.
3. Red dot
Laser is invisible. Red dot shows the laser position on material, for better locating.
4. Auto focusing
Auto focusing has to work together with motorized up-down table. The machine adjusts the focal length automatically before engraving and cutting, which replaces manual focusing, improving working efficiency
1. Q: How should I choose the correct machine for my work?
A: If you know little about laser machines, or no experience with laser machines. Please provide the following information, I will make recommendations for you:
(1) What do you engrave / cut?
(2) What is your Item/material/product size (length and width)?
(3) What is your Item/material/product width?
(4) Please specify if you have special requirements.
2. Q: Why choose us?
A: If you choose us, you will get best quality,best service,best price,best warranty.
3. Q: How to operate the machine?
A: We will deliver English manual and video with the machine to you.If you still need our help,please contact us.
4. Q: How can I get the sample to check you quality?
A: If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.
5. Q: Does the machine can be customized according my requirements?
A: Sure,we have a strong technical team and have rich experience. Our goal is to make you satisfied.
6. Q: Can you arrange shipping for me?
A: We can arrange shipping for our clients accordingly by sea and air. Trading terms FOB, CIF, EXW are available.
1. Q: How should I choose the correct machine for my work?
A: If you know little about laser machines, or no experience with laser machines. Please provide the following information, I will make recommendations for you:
(1) What do you engrave / cut?
(2) What is your Item/material/product size (length and width)?
(3) What is your Item/material/product width?
(4) Please specify if you have special requirements.
2. Q: Why choose us?
A: If you choose us, you will get best quality,best service,best price,best warranty.
3. Q: How to operate the machine?
A: We will deliver English manual and video with the machine to you.If you still need our help,please contact us.
4. Q: How can I get the sample to check you quality?
A: If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.
5. Q: Does the machine can be customized according my requirements?
A: Sure,we have a strong technical team and have rich experience. Our goal is to make you satisfied.
6. Q: Can you arrange shipping for me?
A: We can arrange shipping for our clients accordingly by sea and air. Trading terms FOB, CIF, EXW are available.
