CF1325ATC
Chengfeng
1.The router machine bed is not deformed: Whole machine body is rigid without deformation. The whole body of the bed is seamless welded with tempering aging treatment.
2.CNC Router machine with high processing efficiency: A plate-type blade holder, which can hold 8 pcs blades at the same time. During operation, the automatic change of the blades can improve the processing efficiency, saving the labor cost for manual blade change.
3.CNC Router machine adopts Italy HSD 9.0 KW automatically blade changing spindle:Imported ceramic bearings. Spindle speed is 0-24000rmp, large engraving power and long service life, smooth engraving edge.
4.CNC Router machine adopts Taiwan new generation bus control system:It can be connected with multiple software with advantages of simple operation, quick speed and stable running.
5.CNC Router machine adopts Taiwan's Hiwin linear rail: TBI precision ball screw drive system, Japan's Yaskawa servo drive system (optional domestic servo motor), the machine is of high quality and high precision. Heavy load capacity, smooth operation, long service life, high precision blades.
6.CNC Router machine adopts Taiwan Delta inverter: by changing the frequency of the power supply, It can achieve the purpose of changing the power supply voltage according to the actual needs of the motor,thus achieving energy saving and speed controlling.High speed precision, good stability and wide range of applications.
7.CNC Router machine with Intelligent off-line protection function: It can prevent collision and protect the machine under overprocess.
8.CNC Router machine Equipped with the memory function: which makes it easier to restart form the break point in case of accident stop without any setting-to-work test.
9.Independent cabinet, split keyboard: split keyboard operation, simple and convenient, easy to learn, more independent.
10.Intelligent off-line protection function: It can prevent collision and protect the machine under overprocess. Wireless handle makes operation more convenient and it can control the machine within 20m to stop, suspend, turn home and so on. USB port can support put in data directly from outside.
11.Aluminum T-slot and vacuum adsorption dual-use table: equipped with vacuum adsorption, vacuum cleaner device, for the density board and other soft material processing , can also be placed in different sizes of sheet metal, And the effect of the engraved out of the depth of the same map, but also improve the processing of sheet metal outside the loading and unloading time; vacuum system can be sucked in the processing process of wood chips and debris, to keep the table clean and indirect maintenance of the equipment.
12.Safe operation: the machine has a number of emergency stop switch, which can protect the safety utmost.
1.The router machine bed is not deformed: Whole machine body is rigid without deformation. The whole body of the bed is seamless welded with tempering aging treatment.
2.CNC Router machine with high processing efficiency: A plate-type blade holder, which can hold 8 pcs blades at the same time. During operation, the automatic change of the blades can improve the processing efficiency, saving the labor cost for manual blade change.
3.CNC Router machine adopts Italy HSD 9.0 KW automatically blade changing spindle:Imported ceramic bearings. Spindle speed is 0-24000rmp, large engraving power and long service life, smooth engraving edge.
4.CNC Router machine adopts Taiwan new generation bus control system:It can be connected with multiple software with advantages of simple operation, quick speed and stable running.
5.CNC Router machine adopts Taiwan's Hiwin linear rail: TBI precision ball screw drive system, Japan's Yaskawa servo drive system (optional domestic servo motor), the machine is of high quality and high precision. Heavy load capacity, smooth operation, long service life, high precision blades.
6.CNC Router machine adopts Taiwan Delta inverter: by changing the frequency of the power supply, It can achieve the purpose of changing the power supply voltage according to the actual needs of the motor,thus achieving energy saving and speed controlling.High speed precision, good stability and wide range of applications.
7.CNC Router machine with Intelligent off-line protection function: It can prevent collision and protect the machine under overprocess.
8.CNC Router machine Equipped with the memory function: which makes it easier to restart form the break point in case of accident stop without any setting-to-work test.
9.Independent cabinet, split keyboard: split keyboard operation, simple and convenient, easy to learn, more independent.
10.Intelligent off-line protection function: It can prevent collision and protect the machine under overprocess. Wireless handle makes operation more convenient and it can control the machine within 20m to stop, suspend, turn home and so on. USB port can support put in data directly from outside.
11.Aluminum T-slot and vacuum adsorption dual-use table: equipped with vacuum adsorption, vacuum cleaner device, for the density board and other soft material processing , can also be placed in different sizes of sheet metal, And the effect of the engraved out of the depth of the same map, but also improve the processing of sheet metal outside the loading and unloading time; vacuum system can be sucked in the processing process of wood chips and debris, to keep the table clean and indirect maintenance of the equipment.
12.Safe operation: the machine has a number of emergency stop switch, which can protect the safety utmost.
Model | CF1325ATC |
Frame | Steel Square Tubes up to 8mm, T type |
Table Size | 1500*3040mm |
Working Dimension | 1300*2500*200mm |
Table surface | Bakelite Vacuum Table +Aluminum T-slot Extrusion |
Spindle Power | HQDorItaly HSD 9 kw auto tool change air cooling spindle 24000rpm (ES929)4.5kw(ES330) |
Motor/driver | Servo Motor/driver |
Tool magazine | Carrousel type (linear type is optional) |
Tool change time | 8 seconds (Carrousel type tool magazine) |
Inverter | Taiwan Delta inverter |
Switch and emergency stop | Schneider proximity switch, Omron emergency stop from Japan |
Working speed | 30,000mm/min |
XYZ Travelling Potioning Accuracy | ±0.02/300mm |
Voltage | 380V/220V 3phase |
Repeatability | +/- 0.05mm |
Control System | Taiwan Syntec 6MB control system |
Command | G code |
Optional Device | Coolant Tray, Vacuum Holdingdown Table, Vacuum pump |
Certification | CE |
Weight | 2500kg |
Package Size(L*W*H) | 3.3*2.2*2.2m |
Warranty | 24 months |
